Product Details:
Payment & Shipping Terms:
|
Automatic Grade: | Semi-Automatic | Voltage: | 220v/380v/440v |
---|---|---|---|
Condition: | New | After-sales Service Provided: | Engineers Available To Service Machinery Overseas |
Driven Type: | Electric | Certification: | CE |
Name: | Corrugated Cardboard Single Facer Line | Color: | Customized Color |
Machine Type: | Corrugated Paperboard Making Machine | Usage: | Corrugated Making |
Warranty: | One Year |
1) DWQJ-Z Single Faced Rotary Sheeter rational mechanical structure, strong form, good stability, long use-life.
2) All operation control on the same side, easy to operate, photo-electric counter.
Max Effective Width |
1100~2200mm |
Slitting |
4-slitter |
Cutting Length |
400~2400mm |
Cutting Precision |
±2.5mm |
Design Speed |
80m/min |
DW-80 Single Facer Corrugation Line
1) This product line consists of three single machines, Electrical Shaftless Mill Roll Stand, SF-280 Fingerless type Single Facer, NC Rotary Cutter, Steam Boiler & Pipeline(customer-owned parts), etc.
2) Kraft Paper Reel to corrugate and glue by Corn Starch Gum, continuously produce and cut to Single Faced Corrugated Cardboard Sheet, and then through Flute Laminator Machine or Sheet Pasting Machine to laminate to 3/5-ply corrugated sheet, press and fix.
3) The production line has rational structure design, advanced producing flow, high efficiency, strong batch adjustability, easy operation, etc. good work conditions.
4) It is the ideal and perfect equipment for small or medium carton factories.
Max Effective Width | 1100~2200mm |
Max Paper Roll Diameter | 1400mm |
Max Paper Roll Weight | 2000kg |
Corrugating Roller | Φ280mm, 48CrMo alloy steel, hardness HRC58°-60° |
Cutting Length | 300~9999mm |
Cutting Precision | ±1.5mm |
Design Speed | 80m/min |
Heating Method | Steam Heating |
Economic Working Speed | 60~80m/min |
