High-Speed 2-Ply Corrugator Line, Single Faced Corrugated Cardboard Making Machine
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Automatic Grade: | Automatic | Voltage: | 220v/380v/440v |
|---|---|---|---|
| Condition: | New | After-sales Service Provided: | Engineers Available To Service Machinery Overseas |
| Driven Type: | Electric | Certification: | CE |
| Warranty: | One Year | Name: | Corrugated Cardboard Single Facer Line |
| Color: | Customized Color | Machine Type: | Corrugated Paperboard Making Machine |
| Usage: | Corrugated Making |
DW-150 Single Facer Corrugation Line
1) This product line consists of Hydraulic Shaftless Mill Roll Stand, Auto Splicer, Preheater, SF-320C Fingerless type Single Facer, NC Single Faced Slitter Cutter Stacker, Steam Boiler & Pipeline(customer-owned parts), etc.
2) Kraft Paper Reel to corrugate and glue by Corn Starch Gum, continuously produce and cut to Single Faced Corrugated Cardboard Sheet, and then through Flute Laminator Machine or Sheet Pasting Machine to laminate to 3/5-ply corrugated sheet, press and fix.
3) The production line has rational structure design, advanced producing flow, high efficiency, strong batch adjustability, easy operation, etc. Good work conditions.
4) It is the ideal and perfect equipment for small or medium carton factories.
| Max Effective Width | 1100~2200mm |
| Max Paper Roll Diameter | 1500mm |
| Max Paper Roll Weight | 3000kg |
| Corrugating Roller | Φ320mm, 48CrMo alloy steel, hardness HRC58°-60° |
| Cutting Length | 300~9999mm |
| Cutting Precision | ±1mm |
| Design Speed | 150m/min | |
| Heating Method | Steam Heating | |
| Economic Working Speed | 100~120m/min | |
