Rewinder for 2-Ply Singel Faced Cardboard Corrugating Production Line

China Rewinder for 2-Ply Singel Faced Cardboard Corrugating Production Line supplier
Rewinder for 2-Ply Singel Faced Cardboard Corrugating Production Line supplier Rewinder for 2-Ply Singel Faced Cardboard Corrugating Production Line supplier Rewinder for 2-Ply Singel Faced Cardboard Corrugating Production Line supplier Rewinder for 2-Ply Singel Faced Cardboard Corrugating Production Line supplier Rewinder for 2-Ply Singel Faced Cardboard Corrugating Production Line supplier Rewinder for 2-Ply Singel Faced Cardboard Corrugating Production Line supplier

Large Image :  Rewinder for 2-Ply Singel Faced Cardboard Corrugating Production Line

Product Details:

Place of Origin: China
Brand Name: Yush
Certification: CE
Model Number: DW-60

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: FOB: 15000~25000USD
Packaging Details: Plastic Film or Wooden Box
Delivery Time: 30~60 working days
Payment Terms: T/T
Supply Ability: 15 sets per month
Detailed Product Description
Automatic Grade: Semi-Automatic Voltage: 220v/380v/440v
Condition: New After-sales Service Provided: Engineers Available To Service Machinery Overseas
Driven Type: Electric Certification: CE
Warranty: One Year Name: Corrugated Cardboard Single Facer Line
Color: Customized Color Machine Type: Corrugated Machine/single Facer Machine With Low Price

DW-80 Single Faced Corrugated Cardboard Production Line

1) This product line consists of three single machines, Electrical Shaftless Mill Roll Stand, SF-280 Fingerless type Single Facer, NC Rotary Cutter, Steam Boiler & Pipeline(customer-owned parts), etc.
2) Kraft Paper Reel to corrugate and glue by Corn Starch Gum, continuously produce and cut to Single Faced Corrugated Cardboard Sheet, and then through Flute Laminator Machine or Sheet Pasting Machine to laminate to 3/5-ply corrugated sheet, press and fix.
3) The production line has rational structure design, advanced producing flow, high efficiency, strong batch adjustability, easy operation, etc. good work conditions.
4) It is the ideal and perfect equipment for small or medium carton factories.
5) Equipped with Rewinder unit for 2-ply single faced cardboard rewinding.

Max Effective Width 1100~2200mm
Max Paper Roll Diameter 1400mm
Max Paper Roll Weight 2000kg
Corrugating Roller Φ280mm, 48CrMo alloy steel, hardness HRC58°-60°
Cutting Length 300~9999mm
Cutting Precision ±1.5mm
Design Speed 80m/min
Heating Method Steam Heating
Economic Working Speed 40~80m/min




Single Facer Corrugation Line, Mill Roll Stand + Single Facer + Rotary Cutter

Single Facer Corrugation Line, Mill Roll Stand + Single Facer + Rotary Cutter

Single Facer Corrugation Line, Mill Roll Stand + Single Facer + Rotary Cutter

Single Facer Corrugation Line, Mill Roll Stand + Single Facer + Rotary Cutter
