NC Computer-control Thin Blade Slitter Scorer, Full-automatic Computer Servo control adjustment

Certification
Good quality Flexo Printer Slotter Die-cutter for sales
Good quality Flexo Printer Slotter Die-cutter for sales
I'm Online Chat Now

NC Computer-control Thin Blade Slitter Scorer, Full-automatic Computer Servo control adjustment

China NC Computer-control Thin Blade Slitter Scorer, Full-automatic Computer Servo control adjustment supplier
NC Computer-control Thin Blade Slitter Scorer, Full-automatic Computer Servo control adjustment supplier NC Computer-control Thin Blade Slitter Scorer, Full-automatic Computer Servo control adjustment supplier NC Computer-control Thin Blade Slitter Scorer, Full-automatic Computer Servo control adjustment supplier NC Computer-control Thin Blade Slitter Scorer, Full-automatic Computer Servo control adjustment supplier NC Computer-control Thin Blade Slitter Scorer, Full-automatic Computer Servo control adjustment supplier NC Computer-control Thin Blade Slitter Scorer, Full-automatic Computer Servo control adjustment supplier

Large Image :  NC Computer-control Thin Blade Slitter Scorer, Full-automatic Computer Servo control adjustment

Product Details:

Place of Origin: China
Brand Name: Yush
Certification: CE
Model Number: BFY-NC

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: FOB: 50000~60000USD
Packaging Details: Plastic Film or Wooden Box
Delivery Time: 30~60 working days
Payment Terms: T/T
Supply Ability: 15 sets per month
Detailed Product Description

NC Computer-control Thin Blade Slitter Scorer

1) improved with pre-scoring, 0mm slitting width optional;

2) machine axial electric move 200mm, effective with the paper offset;

3) adopt thin knife high-speed slitting, precision ball screw and linear guide transmission;

4) thin tungsten steel alloy blade, sharp edge, long service life more than 8million meter;

5) upper slitter wheel, upper scoring wheel pneumatic control lift up & down, not to cut off the cardboard while changing orders;

6) computer monitor automatically track the production line speed, to ensure the synchronization;

7) electric sharpening system can achieve the production process, non-stop sharpen blades, sharpening device according to the material or trimming conditions to set at any time, the time interval meter and the time of sharpening;

8) independent stepper motor control each knife stand and wheel stand, could be ranked in the case of non-stop machine, synchronization changing orders, complete and accurate specifications changes in 3-8 seconds;

9) computer storage without limit orders, production output any group of orders, according to the actual needs;

10) imported synchronous belt driver, accurate precision, long life, low noise operation.


Max Effective Width

1100~2200mm

Slitting Knife

4~6 pairs

Min Slitting Distance

180mm

Scoring Wheel

6~10 pairs

Min Scoring Distance

0mm

Design Speed

150~250m/min



Full-automatic Thin Blade Slitter Scorer, Rotary Slitting + Scoring, with Auto Feeder, full-automatic computer controlFull-automatic Thin Blade Slitter Scorer, Rotary Slitting + Scoring, with Auto Feeder, full-automatic computer control

Full-automatic Thin Blade Slitter Scorer, Rotary Slitting + Scoring, with Auto Feeder, full-automatic computer control

Full-automatic Thin Blade Slitter Scorer, Rotary Slitting + Scoring, with Auto Feeder, full-automatic computer control
