Product Details:
Payment & Shipping Terms:
|
| Size: | Made To Customer Request | Voltage: | Customized |
|---|---|---|---|
| Material Compatibility: | Corrugated Cardboard, Paperboard | Condition: | New |
| Warranty: | One Year |
| Printing Nozzle | 8 |
| Printing Nozzle Height | 2~4mm |
| Printing Nozzle Type | Micro-pressure electric high-precision printing nozzle |
| Color Type | C, M, Y, K |
| Ink Type | Water-based ink or UV ink |
| Ink Supply System | Automatic continuous supply ink |
| Software | Special RIP software |
| Operation System | Win7/Win10, 64bits System |
| Feeding Type | Automatic lead-edge feeding |
| Material Thickness | 3~40mm |
| Max Printing Area | 2400 (W) * 1200mm (if manual feeding, length no limit) |
| Printing Precision | Scanning type >= 360*600dpi |
| Capacity | 600m2/hour (8 printing nozzle) |
| Weight & Dimension | about 5000kg, 6000*4000*2200mm |
| Power & Voltage | About 20kw, 380V, 50Hz, 3-phase (made to customer) |
Yush Machine Group Co., Ltd. is a professional enterprise specializing in R&D, production, sales and service of complete manufacturing equipments of corrugated cardboard, hard paperboard, carton, box, paper, etc. (all machines to make according to customer request available)
Our main products consists of
2/3/4-ply Hard Cardboard Production Line, 3/5/7-layer Corrugated Cardboard Production Line (Single Facer Corrugation Line, Flute Laminator, Shaftless Mill Roll Stand, Preheater, Single Facer, Overhead Bridge, Multiple Preheater, Multiple Gluer, Double Facer, NC Thin Blade Slitter Scorer, NC Rotary Cut-off, Conveyor Stacker, NC Duplex Cut-off, NC Double-layer Stacker, etc.)
Carton Box Making Machine (Slitter Scorer, Slotter, Die-cutter, Flexo Printer Slotter Die-cutter Stacker, Folder Gluer, Stitcher, Strapper, etc.)
Paper Box Making Machine (Cardboard Laminator, Film Laminator, Die-cutting and Creasing Machine, Folder Gluer, Cardboard Slotter, Box Corner Gluer, Sheet Feeding and Pasting Machine, etc.)
Paper Products Related Machines (Automatic Paper Roll to Sheet Cutter, Program-control Paper Guillotine, Automatic Slitter Rewinder, Automatic Reel Flexo Printer, Paper Tube & Core Making Machine, Paper Corner Protector Making Machine, Paper Cup Making Machine, Paper Straw Making Machine, Paper Egg Tray Making Machine, Egg Carton Making Machine, etc.)
![]()
![]()
![]()
![]()
Contact Person: Mr. Rayfus
Tel: +86-156-9019-6799
Fax: +86-318-573-6656
