Flexo Printing Plate Making Machine, printing template for Flexo Printer Slotter Die-cutter machine

China Flexo Printing Plate Making Machine, printing template for Flexo Printer Slotter Die-cutter machine supplier
Flexo Printing Plate Making Machine, printing template for Flexo Printer Slotter Die-cutter machine supplier Flexo Printing Plate Making Machine, printing template for Flexo Printer Slotter Die-cutter machine supplier Flexo Printing Plate Making Machine, printing template for Flexo Printer Slotter Die-cutter machine supplier Flexo Printing Plate Making Machine, printing template for Flexo Printer Slotter Die-cutter machine supplier Flexo Printing Plate Making Machine, printing template for Flexo Printer Slotter Die-cutter machine supplier Flexo Printing Plate Making Machine, printing template for Flexo Printer Slotter Die-cutter machine supplier

Large Image :  Flexo Printing Plate Making Machine, printing template for Flexo Printer Slotter Die-cutter machine

Product Details:

Place of Origin: China
Brand Name: Yush
Certification: CE
Model Number: YBJ

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: FOB: 50000~10000USD
Packaging Details: Plastic Film or Wooden Box
Delivery Time: 15~30 working days
Payment Terms: T/T
Supply Ability: 60 sets per month
Contact Now
Detailed Product Description
Type: Carton Box Making Machine After-sales Service Provided: Engineers Available To Service Machinery Overseas
Automatic Grade: Full-Atuomatic Voltage: Customized
Warranty: One Year Color: Customer's Request
Condition: New

Flexo Printing Plate Making Machine

Functional Specifications:

  1. Adopt CO2 laser tube, combining electronics, mechanics, computer technologies.
  2. Laser head and processing material non-touch, non-damage surface, small cutting gap, high precision.
  3. Equipped with slope, front and rear feeding, negative pressure adsorption, offline use, layering, etc. functions.
  4. Adopt stepper motor, water cooling and protection system, equipped with auxiliary exhaust fan and smoke exhaust pipe.
  5. Adopt frame structure, sturdy and durable, equipped with universal truckle and support feet, convenient to move around.
  6. Industrial touch screen colorful display, high sensitivity, long use life.
  7. High precise guide rail, high accuracy, long use life.
  8. Easy operation, safe and high efficiency.

Technical Parameters:

Process Area 900*600mm 1300*900mm
Laser Type Enclosed CO2 laser tube
Laser Power 80W
Working Speed 0~72000mm/min
Re-position Precision ±0.01mm
Minimum Letter English 1*1mm
Working Temperature 0~45℃
Picture Format BMP, PLT, DST, DXF, AI, etc.
Control Software DSP+USB control system
Compatible Software CorelDRAW, AutoCAD, Photoshop, etc.
Working Humidity 5~95%
Total Power About 1000w About 1600w
Voltage 220V±10%, 50Hz, Single-Phase (made to customer request)
Weight About 300kg About 400kg
Dimension About 1600*1200*100mm About 2000*1500*1800mm


Flexo Printing Plate Making Machine, printing template for Flexo Printer Slotter Die-cutter machine

Full Automatic Lead-Edge Feeding Flexo Printer Slotter Die Cutter StackerFull Automatic Lead-Edge Feeding Flexo Printer Slotter Die Cutter StackerFull Automatic Lead-Edge Feeding Flexo Printer Slotter Die Cutter StackerFull Automatic Lead-Edge Feeding Flexo Printer Slotter Die Cutter Stacker
