Automatic Digital Printer Machine, CMYK, Lead-Edge Feeding, high precision
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Type: | Automactic Carton Box Printing Machine | After-sales Service Provided: | Engineers Available To Service Machinery Overseas |
|---|---|---|---|
| Voltage: | Customized | Warranty: | One Year |
| Color: | Customer's Request | Condition: | New |
| Function: | Corrugated Carton Printing |
Automatic Digital Printing Machine
1. Digital printing machine no need of printing template, suitable for small urgent orders of various different desinged carton box.
2. Automatic lead-edge feeding, accurate positioning, little error, stable running, low noise.
3. Touch screen control, simple change orders, easy operation.
2. Automatic lead-edge feeding, accurate positioning, little error, stable running, low noise.
3. Touch screen control, simple change orders, easy operation.
| Printing Nozzle | 8/16 |
| Printing Nozzle Height | 2~4mm |
| Printing Nozzle Type | Micro-pressure electric high-precision printing nozzle |
| Color Type | C, M, Y, K |
| Ink Type | Water-based ink or UV ink |
| Ink Supply System | Automatic continous supply ink |
| Software | Special RIP software |
| Operation System | Win7/Win10, 64bits System |
| Feeding Type | Automatic lead-edge feeding |
| Material Thickness | 3~40mm |
| Max Printing Area | 2500*1300mm (by automatic feeding) 2500mm * length no limit (if by manual feeding) |
| Printing Precision | Scaning type >= 360*600dpi |
| Capacity | 600m2/hour (8 printing nozzle) 1200m2/hour (16 printing nozzle) |
| Dimension | about 6000*4000*2200mm |
| Weight | about 5000kg |
| Voltage | 380V (±10%), 50/60Hz, 3-phase |
| Power | About 20kw |
| Workshop Requirement | Independent, clean, low dust, less light, good ventilation, temperature 20~25oC, humidity 50~70%RH |
| Ventilation Equipment | overhead exhaust fan with a displacement of 600cfm |
