Automatic Multi-function Folder Gluer Machine with Pre-fold & Bottom-lock, by glue guns, option for CD box

China Automatic Multi-function Folder Gluer Machine with Pre-fold & Bottom-lock, by glue guns, option for CD box supplier
Automatic Multi-function Folder Gluer Machine with Pre-fold & Bottom-lock, by glue guns, option for CD box supplier Automatic Multi-function Folder Gluer Machine with Pre-fold & Bottom-lock, by glue guns, option for CD box supplier Automatic Multi-function Folder Gluer Machine with Pre-fold & Bottom-lock, by glue guns, option for CD box supplier Automatic Multi-function Folder Gluer Machine with Pre-fold & Bottom-lock, by glue guns, option for CD box supplier Automatic Multi-function Folder Gluer Machine with Pre-fold & Bottom-lock, by glue guns, option for CD box supplier Automatic Multi-function Folder Gluer Machine with Pre-fold & Bottom-lock, by glue guns, option for CD box supplier

Large Image :  Automatic Multi-function Folder Gluer Machine with Pre-fold & Bottom-lock, by glue guns, option for CD box

Product Details:

Place of Origin: China
Brand Name: Yush
Certification: CE
Model Number: ZH-GQ

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: FOB: 40000~80000USD
Packaging Details: Plastic Film and Wooden Box
Delivery Time: 30~60 working days
Payment Terms: T/T
Supply Ability: 10 sets per month
Contact Now
Detailed Product Description

ZH-GQ Automatic Folder Gluer with Pre-fold & Bottom-lock

(by glue gun, optional for CD box)



1. This machine is specially used for paperboard shaping and adhesive processing after cutting horizontally.
2. Its universality is strong and suitable scope is wide, which can fold and paste various straight seaming box and bottom edging box.
3. It is widely used in food, medicine, cosmetics, stationery and other ordinary cartons, process and glue for all kinds of bottom-locked cartons.
4. Pre-fold section is applied to auto packaging, fold 1 and fold 3 of all cartons can reach 180° and 135° ,perfectly combing the requirements of auto packaging together.

Model ZH-800/1050GQ
Paper Material Cardboard200-800g, E/F-flute
Max. Liner speed Max. 280 meter/minute
Feeding way Automatically and continuously feeding
Way of folding

Fold 1 and fold 3 are 180°and 135°

Fold 2 and fold 4 are 180°

Bottom folded and glued
Glue Material Water-base cold glue
Electric power 7.5kw 380V 50HZ 3P
Weight 3300/3500KG
Over dimension 11500 x (1500/1700) x 1400mm





















Automatic Multi-function Folder Gluer Machine with Pre-fold & Bottom-lock, by glue guns, option for CD box

Automatic Multi-function Folder Gluer Machine with Pre-fold & Bottom-lock, by glue guns, option for CD box

Automatic Multi-function Folder Gluer Machine with Pre-fold & Bottom-lock, by glue guns, option for CD box

Automatic Multi-function Folder Gluer Machine with Pre-fold & Bottom-lock, by glue guns, option for CD boxAutomatic Multi-function Folder Gluer Machine with Pre-fold & Bottom-lock, by glue guns, option for CD box

Automatic Multi-function Folder Gluer Machine with Pre-fold & Bottom-lock, by glue guns, option for CD box

Automatic Multi-function Folder Gluer Machine with Pre-fold & Bottom-lock, by glue guns, option for CD box
