Chain type Rotary Slotter Machine, Combined Adjustment, Slotting + Cutting + Creasing

China Chain type Rotary Slotter Machine, Combined Adjustment, Slotting + Cutting + Creasing supplier

Large Image :  Chain type Rotary Slotter Machine, Combined Adjustment, Slotting + Cutting + Creasing

Product Details:

Place of Origin: China
Brand Name: Yush
Certification: CE
Model Number: FYQ

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: FOB: 10000~15000USD
Packaging Details: Plastic Film or Wooden Box
Delivery Time: 15~30 working days
Payment Terms: T/T
Supply Ability: 30 sets per month
Contact Now
Detailed Product Description

Chain type Rotary Slotter Machine

1) This machine is a whole one for separating the cardboard, rolling the line, cutting the corner and opening the slot at one process.

2) Transmit gear adopt no clearance cooperation, debase gear adjust error.

3) Gears adopt concentrate feeding oil lubricate, low noise, long use-life.

4) 360-degree electric planet gear adjustment phase, speedy and nicety.

5) Slotting knife and corner-cutting knife synchronous adjust carton height.

6) Slotting knife and creasing wheel combined adjust carton length and width, to save time and labor.

Max Sheet size

900*1200mm~1600*3000mm

Min Sheet Size

300*400~500*600mm

Min Slotting Distance

120*120*120*120mm

Max Slot Depth

225~400mm

Design Speed

60pcs/min
